Kia Rio (2nd generation): Wiper Blade Replacement

The wiper blades on the Rio II should be replaced every 6-12 months, depending on how heavily the car is used. The procedure takes only a few minutes and requires no tools.

Difficulty: Easy Time: 5 minutes Steps: 7 Tools: None required

Parts

2
№PartGenuine part no.Alternatives
01 Wiper blade, driver side, 55-60 cm, hook attachment Bosch Aerotwin AR 552 S, Valeo, Denso
02 Wiper blade, passenger side, 40-41 cm, hook attachment 98360-2F000 Bosch Aerotwin AR 552 S, Valeo, Denso

Part numbers are from the manufacturer's original catalogue. Check them against your VIN before ordering.

There's a full repair manual for this car Every system, wiring diagrams and torque specs — not just this job. Haynes and 6 more. See manuals →

Step by step

7 steps
  1. Lift the wiper arm away from the windshield as far as it will go (90 degrees to the glass).
  2. Find the small locking tab on the side of the blade adapter.
  3. Press the locking tab with your finger and at the same time pull the blade down along the arm. It will slide out of the hook.
  4. Take the new blade and line up its adapter with the hook on the arm.
  5. Insert the hook into the slot in the blade adapter and pull the blade upward until it clicks into place.
  6. Gently lower the arm back onto the windshield. Do not let it drop, or you may damage the glass.
  7. Repeat the procedure for the other wiper.

Common mistakes and warnings

  • When lowering the arm onto the windshield, hold it with your hand
  • The spring can snap the metal arm against the glass and leave a chip
  • Check the sizes before buying blades: for the 2009-2011 facelift models, both 55/40 cm and 60/40 cm setups are found
